ADO air One pro
All-in-one freedom for everyday life - from urban streets to countryside escapes. Engineered for everyone everywhere.
- All-in-One Family E-Bike
- Modular Accessories & Mounts
- Torque Sensor & Carbon Belt
- Multi-Scenario Ready
- BFANG Internal Auto-Shift Motor
- Removable & Expandable Battery
General Spec
-
Range
100KM+40KM ( *Dual-Batteries Mode)
-
Speed
25 km/h
-
Certificates
SGS CE
-
Suspension
Adjustable front fork shockabsorbption
-
Transmission
Automatic dual speed
-
Tyre Size
20*2.4 inch
-
Pedal Assist
Torque sensor
-
Assist Intelligent
0-3 level pedal assist
-
Rider Heights
150-190cm
-
Working Temperature
-10~50°C
-
Weight
Net weight: 25+ kg (excluding all accessories)
Full weight: 31+ kg (including all accessories)
Permissible Max. Weight: 150 kg*All stated weight numbers have a +/- 3%-5% tolerance. Net weight includes the battery but excludes all accessories. Full weight includes the battery and all accessories.
Components Spec
-
Frame
Aluminum Alloy
-
Brakes
Forged Aluminum 2 Finger Lever
-
Wheels
Double Walled Aluminum
-
Fork
Lock-out Suspension Fork
-
Headlight
IPX5 Waterproof 1200lumen
-
Transmission system
Belt Drive
-
Mudguard
Iron Mudguard
-
Rear rack
Integrated Aluminum Alloy
Geometry

-
SIZE(mm)
-
Max Seat Height1070
-
Mini Seat Height820
-
Total Length1720
-
Max Handlebar1110
-
Mini Handlebar1040
-
Handlebar width700
-
Handlebar rot-angle90°
